Die-Cast Outdoor LED Egress Emergency Light - Low Profile - Unlimited Lights Project Ready
The Die-Cast Outdoor LED Egress Emergency Light - Low Profile is an emergency light from Exitronix model family NF5-LB-10L-CM-BA for emergency egress illumination. Use the spec-backed details below to confirm fit before adding it to a quote or project order. Key project details include 120/277V, 24V, 120/277VAC, 120VAC, and 277VAC.
Quick fit
- Model or SKU family: NF5-LB-10L-CM-BA.
- Electrical configuration includes 120/277V, 24V, 120/277VAC, and 120VAC.
- Mounting support includes Surface, Wall, Ceiling, and Universal.
- Housing or construction: Polycarbonate, Steel, Aluminum, and Die-Cast Aluminum.
- Location fit: Wet Location, Outdoor, and IP66.
- Spec-listed standards and ratings include UL 924, ETL, NFPA 101, NEC, and IP66.
- Emergency backup: Yes, and No.
Key specifications
| Product family | emergency light |
|---|---|
| Brand | Exitronix |
| Model / SKU family | NF5-LB-10L-CM-BA |
| Voltage | 120/277V, 24V, 120/277VAC, 120VAC, 277VAC, and 120/277 VAC |
| Wattage | 10-29W, Under 10W, 10W, 20W, and 2W |
| Color temperature | 2900K, 3200K, and 3800K |
| Location rating | Wet Location, Outdoor, and IP66 |
| Mounting | Surface, Wall, Ceiling, Universal, Top Mount, and Canopy Mount |
| Housing / construction | Polycarbonate, Steel, Aluminum, Die-Cast Aluminum, Glass, and Cast Aluminum |
| Power source | AC Only, and Battery Backup |
| Emergency light type | Steel Emergency Light, Wet Location Emergency Light, High-Output Emergency Light, and Compact Emergency Light |
| Head count | 2 Heads |
| Emergency backup | Yes, and No |
| Self-testing | Yes |
| Remote capable | No |
| Controls | Photocell |
| Operating temperature | -4°F to 104°F, and -40°F to 122°F |
| Dimensions | 2.5" x 5" |
| Certifications / listings | UL 924, ETL, NFPA 101, NEC, IP66, BABA, and ETL Listed |
Application guidance
Use this emergency light for emergency egress illumination where the housing, head configuration, voltage, and location rating match the project. Confirm spacing, mounting height, and emergency egress requirements with the project plans. Compare related options in Emergency Lights.
Installation and compliance notes
- Install according to the manufacturer instructions and applicable electrical code requirements.
- Confirm final approval requirements with the authority having jurisdiction before ordering for inspected work.
- Match the product voltage to the project circuit: 120/277V, 24V, 120/277VAC, 120VAC, and 277VAC.
- Confirm the installed environment matches the listed location rating: Wet Location, Outdoor, and IP66.
- Keep the spec sheet with project submittals for listed ratings such as UL 924, ETL, NFPA 101, and NEC.
Options and variants
- Power Source | LED Wattage: With Battery | 10W, With Battery | 20W, AC Only | 10W, and AC Only | 20W
- Mounting | Finish: Ceiling Mount | Black, Ceiling Mount | White, Ceiling Mount | Bronze, Mullion Wall Mount Canopy | White, Mullion Top Mount Canopy | White, Wall Mount | Black, Mullion Top Mount Canopy | Brushed Aluminum, and Mullion Top Mount Canopy | Black
- Options: Lens Filter | Self Diagnostics | Security Lighting/Night Lighting: Security Lighting/Night Lighting - 277VAC, Self Diagnostics | Security Lighting/Night Lighting - 277VAC, Self Diagnostics | Security Lighting/Night Lighting - 120VAC, 3800K CCT Lens Filter | Security Lighting/Night Lighting - 120VAC, 3800K CCT Lens Filter | Self Diagnostics | Security Lighting/Night Lighting - 120VAC, 3200K CCT Lens Filter | Self Diagnostics, 2900K CCT Lens Filter | Security Lighting/Night Lighting - 120VAC, and 3800K CCT Lens Filter
- Available SKU examples: NF5-LB-10L-CM-BA, NF5-LB-10L-MTM-BR-32K, NF5-LB-10L-MWM-BA, NF5-LB-10L-MWM-BL, NF5-LB-10L-MWM-BL-32K, NF5-LB-10L-MWM-BR, NF5-LB-10L-WM-BA, NF5-LB-10L-WM-BR and additional configured SKUs.
Documents
Product FAQ
How can this emergency light be mounted?
The source spec indicates Surface, Wall, Ceiling, Universal, and Top Mount mounting support. Confirm the selected variant and installation instructions before release.
What voltage should I confirm before ordering?
Confirm the project circuit matches the product voltage shown in the spec: 120/277V, 24V, 120/277VAC, 120VAC, and 277VAC.
Can this be used in damp or wet locations?
Use the listed environment rating as the guide. This product references Wet Location, Outdoor, and IP66 in the available product data.
Which option should I choose?
Choose the variant that matches the required face count, color, mounting, voltage, or feature package shown in the option selector and SKU list.
What should I review before ordering?
Review the spec sheet, SKU options, mounting conditions, voltage, location rating, lead time, and any job-specific code requirements.
Use this checklist to confirm Die-Cast Outdoor LED Egress Emergency Light - Low Profile - Unlimited Lights Project Ready against the project before ordering. For replacement matching, keep model numbers, photos, cut sheets and quantity notes together.
| Check | What to confirm |
|---|---|
| Compliance | Listing, approval language, project documents and AHJ requirements. |
| Environment | Indoor, damp, wet-location, outdoor, hazardous or high-traffic conditions. |
| Mounting | Wall, ceiling, end mount, pole, height, aiming, face count or fixture clearance. |
| Runtime and power | Voltage, battery backup, emergency runtime, remote capacity or control needs. |
| Compatibility | SKU, lamp/driver/ballast match, dimensions, wiring and accessory requirements. |
| Downloads | Review available cut sheets, install guides and IES files in the product details or request them for quote support. |
