Die-Cast Aluminum LED Exit Sign Battery Backup Option - Green Letters, Single Face
The Die-Cast Aluminum LED Exit Sign Battery Backup Option - Green Letters, Single Face is an exit sign from Exitronix model family G402EX-LB-BA for commercial egress signage. Use the spec-backed details below to confirm fit before adding it to a quote or project order. Key project details include 120/277V, 240V, 120/277VAC, 120V, and 277V.
Quick fit
- Model or SKU family: G402EX-LB-BA.
- Electrical configuration includes 120/277V, 240V, 120/277VAC, and 120V.
- Mounting support includes Surface, Wall, Ceiling, and Pendant.
- Housing or construction: Aluminum, Die-Cast Aluminum, and Cast Aluminum.
- Location fit: Damp Location.
- Spec-listed standards and ratings include UL 924, UL Listed, NFPA 101, NEC, and OSHA.
- Emergency backup: Yes, and No.
Key specifications
| Product family | exit sign |
|---|---|
| Brand | Exitronix |
| Model / SKU family | G402EX-LB-BA |
| Voltage | 120/277V, 240V, 120/277VAC, 120V, 277V, and 277VAC |
| Location rating | Damp Location |
| Mounting | Surface, Wall, Ceiling, Pendant, Back Mount, and Canopy Mount |
| Housing / construction | Aluminum, Die-Cast Aluminum, and Cast Aluminum |
| Exit sign type | LED Exit Sign |
| Letter color | Red, Green, and Black |
| Face count | Single Face, and Double Face |
| Power source | AC Only, Battery Backup, NiCad Battery, and 2 Circuit Input |
| Emergency backup | Yes, and No |
| Self-testing | Yes |
| Operating temperature | 0°C to 50°C, and 32°F to 122°F |
| Certifications / listings | UL 924, UL Listed, NFPA 101, NEC, OSHA, CEC, Title 20, and CEC Compliant |
Application guidance
Use this exit sign for commercial egress signage where the model, voltage, size, and listing details match the existing fixture or project requirement. Compare related options in Exit Signs.
Installation and compliance notes
- Install according to the manufacturer instructions and applicable electrical code requirements.
- Confirm final approval requirements with the authority having jurisdiction before ordering for inspected work.
- Match the product voltage to the project circuit: 120/277V, 240V, 120/277VAC, 120V, and 277V.
- Confirm the installed environment matches the listed location rating: Damp Location.
- Keep the spec sheet with project submittals for listed ratings such as UL 924, UL Listed, NFPA 101, and NEC.
Options and variants
- Voltage | Finish: 277 V | Black w/ Alum. Face, 277 V | White w/ White Face, 277 V | Brushed Alum. w/ Alum. Face, 277 V | Black w/ Black Face, NiCad Battery (std) | Black w/ Alum. Face, NiCad Battery (std) | White w/ White Face, NiCad Battery (std) | Brushed Alum. w/ Alum. Face, and NiCad Battery (std) | Black w/ Black Face
- Options: Voltage | Self Diagnostics | Tamper Proof: Self Diagnostics | Tamper Proof, Self Diagnostics, 220-240VAC 50Hz Input | Self Diagnostics, 220-240VAC 50Hz Input | Self Diagnostics | Tamper Proof, 220-240VAC 50Hz Input, 220-240VAC 50Hz Input | Tamper Proof, and Tamper Proof
- Available SKU examples: G402EX-LB-BA, G402EX-LB-BA-220V, G402EX-LB-BA-TRH, G402EX-LB-BA-220V-TRH, G402EX-LB-BB, G402EX-LB-BB-220V, G402EX-LB-BB-TRH, G402EX-LB-BB-220V-TRH and additional configured SKUs.
Documents
Product FAQ
How can this exit sign be mounted?
The source spec indicates Surface, Wall, Ceiling, Pendant, and Back Mount mounting support. Confirm the selected variant and installation instructions before release.
What voltage should I confirm before ordering?
Confirm the project circuit matches the product voltage shown in the spec: 120/277V, 240V, 120/277VAC, 120V, and 277V.
Can this be used in damp or wet locations?
Use the listed environment rating as the guide. This product references Damp Location in the available product data.
Which option should I choose?
Choose the variant that matches the required face count, color, mounting, voltage, or feature package shown in the option selector and SKU list.
What should I review before ordering?
Review the spec sheet, SKU options, mounting conditions, voltage, location rating, lead time, and any job-specific code requirements.
Use this checklist to confirm Die-Cast Aluminum LED Exit Sign Battery Backup Option - Green Letters, Single Face against the project before ordering. For replacement matching, keep model numbers, photos, cut sheets and quantity notes together.
| Check | What to confirm |
|---|---|
| Compliance | Listing, approval language, project documents and AHJ requirements. |
| Environment | Indoor, damp, wet-location, outdoor, hazardous or high-traffic conditions. |
| Mounting | Wall, ceiling, end mount, pole, height, aiming, face count or fixture clearance. |
| Runtime and power | Voltage, battery backup, emergency runtime, remote capacity or control needs. |
| Compatibility | SKU, lamp/driver/ballast match, dimensions, wiring and accessory requirements. |
| Downloads | Review available cut sheets, install guides and IES files in the product details or request them for quote support. |
