LED Constant Power Emergency Driver Dual 120/277 Volt


Your Price:
$76.99

Quantity:

Buy in bulk and save
Typically ships within 2-3 business days.

4 Great Reasons To Buy From Us:

  • Image of Image of Image of
  • Image of Image of Image of
  • Image of Image of Image of
  • Image of Image of Image of
Emergency backup power for the line of LED light panels.

ILLUMINATION
  • Provides constant power output to the load during emergency mode operation.
  • Can be operated as NORMALLY-ON, NORMALLY-OFF or SWITCHED LOAD.

ELECTRICAL
  • Dual 120V/277V standard.
  • Charge rate/power "ON” LED indacator light and push-to-test switch for mandated code compliance testing.
  • Long life, maintenance free, rechargeable sealed NiCd battery.
  • Output short/overcurrent protection: Electronic limiting, with normal operation resuming upon removal of fault.
  • 90 Minute minimum emergency operating time over full temperature range (other run times available upon request).
  • Output classification: Class 2 Compliant.
  • Surge protection: Per C62.41 (TVS).
  • Input overcurrent protection: Fusable link.
  • 24 hour maximum battery recharge time.

HOUSING
  • LED illuminated and remote mounted test switch.
  • Injection-molded, engineering grade, 5VA flame retardant, high-impact resistant, thermoplastic in a black finish.

MOUNTING
  • Suitable for installation inside, on top or in remote of the fixture.

WARRANTY/LISTING
  • UL Classified for factory or field installation.
  • Suitable for damp locations (0°C - 50°C).
  • 5 year warranty
