Advance 72C5282NP001 Metal Halide Ballast 70W M98/143 120/277V
Regular price
$183.99
Couldn't load pickup availability
Got questions?
Give us a call 800-847-1955!
Advance 72C5282NP001 Metal Halide Ballast 70W M98/143 120/277V Fcan
Technical Description:
12 Inch Length X 3.9 Inch Width X 2.6 Inch Height Size; -20 Deg F min. Starting Temperature; 60 Hertz Frequency Rating; UL 1029, CSA 22.2 Approval; NEMA 1, Indoor/Outdoor Enclosure; Metal Halide Lamp Type; 70 Watt Lamp Wattage; 120/277 Volt Input Voltage
UPC: 78108702525
Part Number: 72C5282NP001
Manufacturer: ADVANCE TRANSFORMERS
| UPC: | 78108702525 |
| Lamp Wattage: | 70 Watt |
| Circuit Type: | HX-HPF |
| ANSI Code: | M98 (Pulse Start) |
| Minimum Starting Temperature: | -20 Deg F |
| Enclosure: | NEMA 1, Indoor/Outdoor |
| Size: | 12 Inch Length x 3.9 Inch Width x 2.6 Inch Height |
| Approval: | UL 1029, CSA 22.2 |
| Additional Information: | RoHS Compliant |
| Catalog Number: | 72C5282NP001 |
| Brand Name: | Philips |
| Model: | 72C |
| Input Voltage: | 120/277 Volt |
| Input Current: | 0.85 Amp at 120 Volt, 0.37 Amp at 277 Volt |
| Input Power: | 94 Watt |
| Frequency Rating: | 60 Hertz |
| Lamp Type: | Metal Halide |
| CATALOG DESCRIPTION: | VERSATILITY IN COMMERCIAL APPLICATIONS LOW NOISE FOR INDOOR USE;TWO DUAL VOLTAGE CONFIGURATIONS AVAILABLE: 120V/277V FOR THE U.S MARKET AND 120V/347V FOR THE CANADIAN MARKET THE PHILIPS ADVANCE LINE OF F-CAN HID BALLASTS COMES IN TWO DUAL-VOLTAGE CONFIGURATIONS FOR THE US AND CANADIAN MARKET. BALLASTS FOR THESE LUMINAIRES ARE MOST OFTEN ENCASED AND POTTED IN FLUORESCENT BALLAST TYPE CANS. UTILIZES UL CLASS A (90C) INSULATION;HAS BUILT-IN, AUTOMATICALLY RESETTING, THERMAL PROTECTOR WHICH DISCONNECTS THE BALLAST FROM POWER LINE IN THE EVENT OF OVERHEATING OFFICES, SCHOOLS, AND RETAIL STORES |
| Category: | Pulse Start Hid Ballasts |
| Full Technical Description: | 12 Inch Length X 3.9 Inch Width X 2.6 Inch Height Size; -20 Deg F min. Starting Temperature; 60 Hertz Frequency Rating; UL 1029, CSA 22.2 Approval; NEMA 1, Indoor/Outdoor Enclosure; Metal Halide Lamp Type; 70 Watt Lamp Wattage; 120/277 Volt Input Voltage; 0.85 Amp at 120 Volt, 0.37 Amp at 277 Volt Input Current; Hx-Hpf Circuit Type; 94 Watt Input Power; M98 (Pulse Start) ANSI Code; RoHS Compliant; 72C Model |
| Made in USA: | Yes |
| Manufacturer: | Philips USA |
| Manufacturer Brand: | Philips Advance |
| Product Description: | Advance 72C5282NP001 Metal Halide Ballast 70W M98/143 120/277V Fcan |
| Sub-Category: | Indoor/Outdoor Enclosed HID Ballast |
| UNSPSC: | 39101902 |
| UPC 12 Digit: | 781087025253 |
| Unique Product Key: | 675069 |
| comm code enhanced: | 73230 |
